iX PC Mini 5100 Wifi Windows 11 IoT

OS:Windows 11 IoT Enterprise 2024 LTSC

Processor: Intel® Celeron® Processor N5100 4M Cache, up to 2.80 GHz

Storage: 128GB eMMC

Memory: LPDDR5 8GB (onboard memory) Up to 16G

Network : RJ45

SKU: CPN06763

EAN:818391004480

DESCRIPTION

iX PC PLUS RJ45 Model – Fanless Thin Client with Windows 11 IoT 2024 LTSC and WiFi 6

Compact, High-Performance Thin Client Managed by Xcalibur Global

The iX PC PLUS RJ45 Model by Chip PC Technologies is a fanless thin client designed to deliver silent, efficient, and secure performance. Powered by Windows 11 IoT 2024 LTSC and equipped with WiFi 6 connectivity, this compact device ensures seamless integration into modern workspaces and virtual desktop environments. Managed by Xcalibur Global, it offers centralized and streamlined IT control, perfect for those seeking the iX PC Plus Windows 11 IoT thin client solution.

Key Features

Operating System: Windows 11 IoT 2024 LTSC – optimized for long-term support, stability, and security within an iX PC Plus thin client environment.
Management: Xcalibur Global enables centralized monitoring, updates, and device management.
Design: Fanless, compact, and durable, ideal for noise-sensitive environments.
Performance: 8GB LPDDR5 RAM and 128GB eMMC, expandable with an M.2 slot.
Connectivity:
- WiFi 6 (802.11ax): Ultra-fast wireless speeds with improved range and reduced latency.
- 2.5Gbps RJ45 Ethernet: Reliable high-speed wired networking.
- Comprehensive ports: 2x USB 3.2, 2x USB-C, 4x USB 2.0, HDMI 2.0, 2x DisplayPort 1.4, and an audio/mic jack.
Security: Built-in TPM 2.0 for robust data encryption and secure device authentication, vital for any thin client running Windows 11 IoT.

Why Choose the iX PC PLUS RJ45?

Silent Operation: Fanless design ensures quiet and reliable performance.
Advanced Connectivity: WiFi 6 and 2.5Gbps Ethernet provide flexibility for both wireless and wired networking.
Eco-Friendly: Low power consumption reduces operational costs and supports sustainability.
Virtual Desktop Ready: Optimized for RDS, Citrix, and VMware environments, showcasing the strength of the Windows 11 IoT thin client.

Applications

Corporate Offices: Flexible and secure for enterprise use with robust wireless and wired options afforded by the iX PC plus thin client solution.
Education: Quiet, fast, and reliable for classrooms and labs.
Healthcare: Silent and secure, perfect for compliance-sensitive environments.

PRODUCT VIDEO

PRODUCT SPECIFICATIONS

Operating System

Windows 11 IoT Enterprise 2024 LTSC

Processor

Intel® Celeron® Processor N5100 4M Cache, up to 2.80 GHz

Storage

128GB eMMC(onboard)

M.2 SATA\NVMe Up to 2 TB (Optional)

Memory

8GB SO-DIMM DDR4 (Supports up to 32GB)

Input/Output ports

1x Power button, power LED

2 x USB3.2 10GB/S

2 x USB-C 10GB/S

4 x USB 2.0

1 x Combo Audio Port (3.5mm)

1 x Rj45 2.5 Gb

1 x HDMI 2.0

2 x Display Port1.4a

1 x DC IN（12V）

Kensington Lock

Display Support

2 x HDMI

Resolutions

HDMI – Up to 4096×2160@60Hz

Audio Support

Combo Audio Port (3.5mm, 1/8 inch) Audio Jack

Network

RJ45: 10/100/1000 Mbps

Power

Device input: 100～240VAC@50/60HZ

Device Output: 12VDC/5A external power adapter

Humidity

Operating Temperature: 0 ~ 60° C
Storage Temperature: -20 ~ 85° C
Humidity: 10% ~ 90% RH @40°C (non-condensing)

Dimensions

123mm X 115mm X47mm

Warranty

Three-year hardware warranty Optional extended Warranty for years 4 & 5.

Processor

CPU	Alder Lake-N N100 6W 4C/4T Max3.4GHz
Clock frequency	2.8 GHz
Maximum speed in Turbo mode	3.4GHz
Number of hearts	Quad-core (4)
Number of CPUs	1
Maximum number of CPUs	1
Main processor features	4 Threads

Cache memory

Installed size	6 MB
Cache per processor	6 MB

RAM

Installed size	LPDDR5 8GB (onboard memory) Up to 16G
Technology	LPDDR5-4800, 8GB
Effective memory speed	4800 MHz
Nominal memory speed	4800 MHz
Format	LPDDR5 onboard memory
Locations	1 (Total)
Configuration features	Onboard

Storage

capacity	128GB eMMC(Onboard )
Maximum capacity	128GB eMMC(Onboard )
Kind	Flash
Ability	128GB eMMC (Onboard ) 1 x M.2 SATA\NVMe Up to 2 TB (Optional)

Graphics Controller

Graphics Processor	Intel UHD Graphics
Video interfaces	1 x HDMI 2.0- Up to 4096×2160@60Hz 2 x Display Port1.4 – Up to 4096×2160@60Hz

Networks

Interface type (bus)	RJ45: 10/100/1000/2500 Mbps
Ethernet controler	1 x RJ45
Wireless LAN supported	YES
Wireless NIC Card	WiFi 6 (802.11ax, Dual Band 2.4GHz/5GHz) + Bluetooth 5.2
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth 5.2
Features	Double flow (2 x 2)

Audio output

Speakers included	No

Extension/connectivity

Locations	1 x (Onboard ) 1 x M.2 Card – 2230 (Optional)
Interfaces	2 x USB3.2 10GB/S 2 x USB-C 10GB/S 4 x USB 2.0 1 x Combo Audio Port (3.5mm) 1 x RJ45 2.5GB 1 x HDMI 2.0 2 x Display Port1.4 1 x DC IN

Miscellaneous

Accessories included	VESA support (sold separately)
Anti-theft/anti-intrusion protection	Safety lock slot (cable lock sold separately), padlock loop
Type of security housing	Kensington Security Lock (cable not included)

Power Supply

Device Type	AC adapter
Required voltage	AC 100-240 V (50/60 Hz)
Power supply provided	DC+12V 2.5A

Operating System / Software

Operating system provided	Windows 11 IoT Enterprise 2024 LTSC

Dimensions and weight

Width	147 mm
Depth	106 mm
Height	35 mm
Weight	300 gr
Packed weight	1 kg

Environmental characteristics

Minimum operating temperature	0° C
Maximum operating temperature	60° C
Operating humidity level	Humidity: 10% ~ 90% RH @40°C (non-condensing)
